APC PROTECTNET WITH GIGABIT PROTECTION

Forsiden UPS & Power Surge Protect APC PROTECTNET WITH GIGABIT PROTECTION
For at se vore priser skal du være oprettet som kunde: Er du allerede oprettet som kunde skal du logge ind.
APC PROTECTNET WITH GIGABIT PROTECTION (PNET1GB)
APC PROTECTNET WITH GIGABIT PROTECTION (PNET1GB)
APC PROTECTNET WITH GIGABIT PROTECTION (PNET1GB)
APC PROTECTNET WITH GIGABIT PROTECTION (PNET1GB)

APC PROTECTNET WITH GIGABIT PROTECTION

Varenr.:
PNET1GB
EAN:
0731304226734
  • Type PDU tilbehør
Beskrivelse

APC PROTECTNET WITH GIGABIT PROTECTION


Standalone data-line surge suppression for network, telecommunication and PC system protection.

Includes: 15 cm Network Patch Cable(s), User Manual

Product Overview

PNET1GB Features

Catastrophic Event Protection

ProtectNet Features

Protection

Data-line Protection Protection against powers spikes traveling through data lines ensures complete protection of your equipment from surges. It is very important to protect your equipment from "back door" surges traveling through data lines, as they can be as damaging to your equipment as surges traveling over power lines.
Fail Safe Mode Most other surge suppressors continue to let power through even after their circuits have been damaged, leaving your equipment exposed to future surges. APC's Surge Protectors fail safe, which means that once the circuit of an APC Surge Protector has been compromised the unit disconnects equipment from the power supply ensuring that no damaging surges reach your equipment.
Lightning and Surge Protection A protection plan incorporating data line and AC line surge suppression will “bullet-proof” your system against the hazards of surges caused by lightning faults and electro-static discharge.


Technical Specifications

Input

Input Connections
--

Surge Protection and Filtering

Peak Current Normal Mode 6.50 kAmps
Peak Current Common Mode 0.25 kAmps
NM Surge Response Time (ns) 1 ns
Dataline protection RJ45 10/100/1000 Base-T Ethernet protection
Data Lines Protected
(multi-line only)
1-8
Let Through Voltage Rating < 60

Physical

Net Weight 0.11 lbs. ( 0.05 kg)
Maximum Height 4.10 inches (104 mm)
Maximum Width 1.87 inches ( 47 mm)
Maximum depth 1.10 inches ( 28 mm)
Shipping Weight 0.25 lbs. ( 0.11 kg)
Shipping Height 4.10 inches (104 mm)
Shipping Width 3.55 inches ( 90 mm)
Shipping Depth 1.15 inches ( 29 mm)
Master Carton Units 144.00
Master Carton Dimensions (Length x Width x Height) 21 x 23 x 17 inches
Master Carton Weight 46.20 lbs.
SCC Codes 1073130422673 1
Color Beige
Units per Pallet 1152.00

Environmental

Operating Environment 5 - 149 °F (-15 - 65 °C)
Operating Relative Humidity 0 - 95%
Storage Temperature 5 - 149 °F (-15 - 65 °C)
Storage Relative Humidity 0 - 95%

Conformance

Regulatory Approvals UL 497B
Standard Warranty Lifetime
UL 1449 TVSS Rating 330 V

Selvom vi gør vort bedste for at give fyldestgørende information, så er billederne kun vejledende, og selve varen er ikke nødvendigvis 100% identisk med det viste billede. Produkter kan være vist med ekstraudstyr der ikke er inkluderet eller i andre form- og farvevarianter. Hvis der er forskel mellem produktoverskrift, beskrivelse og billede, så er det produktoverskriften som gælder. Hvis du er i tvivl, så kontakt os gerne. Vi tager forbehold for trykfejl, ændring af priser og specifikationer uden varsel.
