APC PROTECTNET WITH GIGABIT PROTECTION
Standalone data-line surge suppression for network, telecommunication and PC system protection.
Includes: 15 cm Network Patch Cable(s), User Manual
Product Overview
PNET1GB Features
Catastrophic Event Protection
Protection
Data-line Protection
| Protection against powers spikes traveling through data lines ensures complete protection of your equipment from surges. It is very important to protect your equipment from "back door" surges traveling through data lines, as they can be as damaging to your equipment as surges traveling over power lines.
|
Fail Safe Mode
| Most other surge suppressors continue to let power through even after their circuits have been damaged, leaving your equipment exposed to future surges. APC's Surge Protectors fail safe, which means that once the circuit of an APC Surge Protector has been compromised the unit disconnects equipment from the power supply ensuring that no damaging surges reach your equipment.
|
Lightning and Surge Protection
| A protection plan incorporating data line and AC line surge suppression will “bullet-proof” your system against the hazards of surges caused by lightning faults and electro-static discharge. |
Technical Specifications
Input
Surge Protection and Filtering
Peak Current Normal Mode
| 6.50 kAmps
|
Peak Current Common Mode
| 0.25 kAmps
|
NM Surge Response Time (ns)
| 1 ns
|
Dataline protection
| RJ45 10/100/1000 Base-T Ethernet protection
|
Data Lines Protected (multi-line only)
| 1-8
|
Let Through Voltage Rating
| < 60 |
Net Weight
| 0.11 lbs. ( 0.05 kg)
|
Maximum Height
| 4.10 inches (104 mm)
|
Maximum Width
| 1.87 inches ( 47 mm)
|
Maximum depth
| 1.10 inches ( 28 mm)
|
Shipping Weight
| 0.25 lbs. ( 0.11 kg)
|
Shipping Height
| 4.10 inches (104 mm)
|
Shipping Width
| 3.55 inches ( 90 mm)
|
Shipping Depth
| 1.15 inches ( 29 mm)
|
Master Carton Units
| 144.00
|
Master Carton Dimensions (Length x Width x Height)
| 21 x 23 x 17 inches
|
Master Carton Weight
| 46.20 lbs.
|
SCC Codes
| 1073130422673 1
|
Color
| Beige
|
Units per Pallet
| 1152.00 |
Operating Environment
| 5 - 149 °F (-15 - 65 °C)
|
Operating Relative Humidity
| 0 - 95%
|
Storage Temperature
| 5 - 149 °F (-15 - 65 °C)
|
Storage Relative Humidity
| 0 - 95% |
Regulatory Approvals
| UL 497B
|
Standard Warranty
| Lifetime
|
UL 1449 TVSS Rating
| 330 V
|
Spidsstrøm, normal tilstand | 6,5 A |
Spidsstrøm, almindelig modus | 0,25 A |
Ethernet LAN-porte (RJ-45) | 1 |
Produktfarve | Grå |
Stativ-montering | Nej |
Responstid | 1 ms |
Mængde pr. kasse | 1 stk |
Bredde | 47 mm |
Dybde | 28 mm |
Højde | 104 mm |
Driftstemperatur (T-T) | -15 - 65 °C |
Opbevaringstemperatur (T-T) | -15 - 65 °C |
Relativ luftfugtighed ved drift (H-H) | 0 - 95% |
Relativ luftfugtighed ved opbevaring (H-H) | 0 - 95% |
Pakkebredde | 29 mm |
Pakkedybde | 90 mm |
Pakkehøjde | 104 mm |
Pakkevægt | 110 g |
